Half Wedge

A ridge: a triangular prism whose two sloped sides meet at a peak centered across its Width, like a roof. Useful for roof shapes, ridges and pointed features.

20260318 183405 paste 20260318 183405

Parameters

  • Width - Size along the X axis, across the two slopes, in mm (default 20)
  • Depth - Size along the Y axis, the length of the ridge, in mm (default 20)
  • Height - How tall the peak is, in mm (default 10)

Tips

  • For a single slope, like a ramp, use a Wedge
  • Combine with other shapes to create angled transitions
